Understanding Characteristics Of Diac, Triac and SCR
Description & Specification
Understanding Characteristics of DIAC, TRIAC & SCR is remarkable and frequently used laboratory equipment which is designed to explain fundamentals and working of DIAC, TRIAC & SCR. By using this product student can understand the basic concept of DIAC, TRIAC & SCR which are the basic devices used in Power Electronics.V-I Characteristics can be drawn by the student which helps them to understand the behavior of these devices easily. This product has suitable in-built power supply and on-board resistor of different values. Breadboard area allows construction of circuits using external components along with on – board resources. Understanding Characteristics of DIAC, TRIAC & SCR is an ideal platform to enhance education, training, skills & development among our young minds.
FEATURES:-
Generalized design
In- built Power supply of +15, +35V and -35V
DPM Based highly perceived on-board Voltmeter & Ammeter
Breadboard
Provided with different values of resistances
10 turn potentiometer
SCOPE OF LEARNING:-
To study and plot the V-I Characteristics of DIAC with Positive and Negative biasing
Study and observation of Break over voltage (V) and V Symmetry of BO DIAC
To study and plot the V-I Characteristic of TRIAC with Positive and Negative biasing
Study of Gate Current Triggering of TRIAC
To study the phenomena of Holding Current and Latching current in TRIAC
To Study and plot V-I Characteristic of SCR Study of Gate Current Triggering of SCR
To study the phenomenon of holding current and latching current in SCR Under
TECHNICAL SPECIFICATIONS:-
Mains power supply : 90 – 270V ±10%, 50Hz
Fixed DC power supply : +15V, Regulated +35V, Regulated -35V, Regulated
Bread Board Distribution strips : 2
Terminal strips : 1
Distribution holes : 200
Terminal holes : 640
Variable Resistance bank5K 10 turn Potentiometer
Voltmeter Range : 0V to 99V
Ammeter Range : 0mA to 20Ma
